Giantplus GPT002A0 LCD

Specification

Model P/N:GPT002A0
Brand:Giantplus
Diagonal Size:8.0"
Resolution:1280(RGB)×800, WXGA 188PPI
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:70/70/70/70 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, Assembly
Pixel Format:RGB Vertical Stripe
Active Area:172.8(W)×108(H) mm
Bezel Opening:-
Outline Dim:198.7(H)×140.6(V) mm
Treatment:Hard coating (7H)
Luminance:600 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:-
Support Color:16.7M 50% NTSC
Light Source:WLED [8S3P] , W/O Driver
Weight:-
Designed For:Industrial
Frame Rate:60Hz
Touch Panel:PCAP, USB
Interface Type:LVDS (1 ch, 8-bit) , 26 pins FPC
Power Supply:3.3/3.3/3.3/5.0V (Typ.)(VCC/VEDID/VCC1/VCC2)
