| Facteur de forme |
ATXFull Size CPU Card |
| Chipset Ethernet |
Intel 82551 |
| Système Chipset |
Intel 875P |
| Audio |
ICH5R integrated audio with AC97 codec, ALC650,Supports 5.1 channel |
| BIOS |
Award BIOS, ACPI supported |
| Jeu de puces |
Intel 875P Chipset |
| UNITÉ CENTRALE |
Intel Pentium 4 with Hyper Threading Technology,2.0GHz ~ 3.2GHz+ |
| CPU Front Side Bus |
800MHz/533MHz/400MHz |
| Socle de l'unité centrale |
Socket 478 |
| Dimensions |
338mm x 122mm (13.3″ x 4.8″) |
| Extra Features |
ISA High Drive,PCI to ISA Bridge (ITE 8888),One MicroAGP socket,ATX 12V power connector |
| FDD Interface |
Supports up to two floppy disk drives: 3.5″ and/or 5.25″ drives; 3 Mode support |
| Hardware Monitoring |
Built in W83627HF; monitors system/CPU temperature and voltage status |
| Interface IDE |
ICH5R built-in IDE1, IDE2 (Ultra DMA 33//66/100) |
| IrDA |
Pin-header |
| Keyboard and Mouse Connector |
PS/2 type |
| Cache L2 |
256K/512K, CPU integrated |
| LPC I/O |
Winbond 83627HF LPC I/O supports IrDA, LPT, Com1 (RS232), COM2 (RS232/422/485), FDC and hardware monitoring |
| MicroAGP VGA |
ATI Mobility M7 VGA, 32MB frame buffer (DDR) via IBA110-32, supports CRT, LVDS, TV-out, 2nd CRT,ATI Mobility M9 VGA, 64MB frame buffer (DDR) via IBA110-64, supports CRT, LVDS, TV-out, 2nd CRT,ATI Mobility M10 VGA, AGP8X, 64MB frame buffer (DDR) via IBA110-64A, supports CRT, LVDS, TV-out, 2nd CRT |
| Parallel Port |
One parallel port supports SPP/EPP/ECP |
| Consommation électrique |
Pentium 4 2.2G Hz/FSB 400MHz with 512MB DDR SDRAM, +5V: 3.74A +12V: 4.59A,Pentium 4 3GHz-HT/FSB 800MHz with 512MB DDR SDRAM,+5V: 3.70A +12V: 6.60A |
| Primary LAN |
Intel 82551QM 10/100Mb Ethernet controller |
| Processeur |
Intel Pentium 4 Celeron |
| Secondary LAN (optional) |
Intel 82547GI Gigabit Ethernet controller |
| Serial ATA |
Two SATA ports, support RAID 0 or RAID 1 |
| Serial Ports |
One RS-232/422/485 and one RS-232 port |
| Solid State Disk Interface |
DiskOnChip socket, supports up to 288MB |
| Mémoire du système |
Two sockets supports up to 2GB DDR266/333/400 memory,Support s dual channel, ECC function |
| USB |
Supports 4 USB ports, USB 2.0 compliant |
| Minuterie chien de garde |
Generates system reset; 256 levels |
