PROCESSOR
Intel® CoreTM i7-860 2.80GHz/8M
Intel® CoreTM i5-750 2.66GHz/8M
Intel® CoreTM i5-660 3.33GHz/4M
Intel® CoreTM i3-540 3.06GHz/4M
Intel® Pentium® G6950 2.80GHz/3M
CHIPSET
Intel® Q57 PCH
Mémoire
Four 240-pin DDR3 DIMM up to 16GB
Dual channel DDR3 1333MHz
BIOS
AMI SPI 64Mbit
Graphique Contrôleur
Intel® HD Graphics
Feature
Supports 3D, 2D and video capabilities
Note: Both Intel® CoreTM i7-860 and Cor
Affichage
1 x DVI-I (DVI-D signal)
1 x VGA
VGA display resolution up to 2048×1536
Expansion Interface
1 x PCIe x16 slot (Gen 2)
1 x PCIe x4 slot (Gen 1)
2 x PCIe x1 (Gen 1)
3 x PCI
Audio
Audio Codec
Realtek ALC262
Ethernet Contrôleur
1 x Realtek RTL8111DL PCIe (10/100/1000Mbps)
1 x Intel® W82578DM PCIe with iAMT6.0 (10/100/1000Mbps)
Rear I/O
Ethernet
2 x GbE (RJ45)
En série
2 x RS232 (DB-9)
USB
4 x USB 2.0
PS/2
2 x PS/2 (mini-DIN-6)
Affichage
1 x DVI-I (DVI-D signal)
1 x VGA (DB-15)
Audio
1 x Line-in
1 x Line-out
1 x Mic-in
|
Internal I/O
En série
2 x RS232/485
USB
8 x USB 2.0
Audio
1 x Line-out
1 x Mic-in
SATA
6 x SATA 2.0 (up to 3Gb/s)
RAID 0/1/5/10
DIO
1 x 8-bit DIO
Minuterie chien de garde
Output & Interval
System Reset, Programmable via Software from 1 to 255 Seconds
Security
TPM
Available Upon Request
Puissance
Type
ATX
Connecteur
24-pin ATX power
8-pin 12V power
Consumption
64.45 W with i7-860 at 2.80GHz and 2x 1GB DDR3 DIMM
Environnement
Température
Operating: 0 to 60°C Storage: -20 to 85°C
Humidité
Operating: 10% to 90% RH Storage: 10 to 90% RH
Dimensions
ATX form factor 305mm (12") x 244mm (9.6")
|
