Caractéristiques
CPU: Onboard Intel® FCBGA8 45nm AtomTM N270 Processor
FSB: 533 MHz
Bios: Award 16Mb SPI BIOS
System Chipset: Intel® 945GSE + ICH7-M Chipset
I/O Chip: Winbond W83627DHG-A
System Memory: One 200-pin SODIMM up to 2GB Single Channel DDR2 533 SDRAM, non-ECC
SSD: One CompactFlash Type I/II socket
Watchdog Timer: Reset: 1 sec. to 255 min. and 1 sec. or 1 min./step
H/W Status Monitor: Monitoring temperatures, voltages, and cooling fan status. Auto throttling control when CPU overheats
Expansion: 1 PCI (PCI Rev. 2.3 compliant), 1 Mini PCI-E
S3/S4: Yes
TPM: Optional, TPM1.2 (Infineon TPM chip 9635 TT 1.2)
Wake up on: LAN or Ring LAN (PME/RPL)
MIO: 1 EIDE, 2 SATA II, 8 RS-232, 1 K/B, 1 Mouse
USB: 6 USB 2.0
GPIO: 16-bit General Purpose I/O for 8-bit DI and 8-bit DO
Chipset: Intel® 945GSE integrated Graphics Media Accelerator 950
Display Memory: Intel® DVMT 3.0 supports 224MB video memory
Max. Resolution: CRT: Supports up to QXGA (2048 x 1536),LVDS: Supports up to UXGA (1600 x 1200)
Dual Display: VGA+18-bit LVDS or VGA+24-bit LVDS
VGA: On board GMA 950 supports CRT resolution up to QXGA
LVDS: Dual channel LVDS resolution up to UXGA, 18-bit and 24-bit Single/Dual channel
LVDS Backlight: Yes
Power Connector: 1 12V CPU Fan Connector, 1 12V Chassis Fan Connector
Audio Codec: Realtek ALC888, 5.1 + 2 CH HD Audio
Audio Interface: Mic-in, Line-in, Line-out
Audio Amplifier (W): Optional, TPA3005D2 Stereo 6 Watt
LAN1: Realtek RTL8111C Gigabit LAN
LAN2: Realtek RTL8111C Gigabit LAN
