| Facteur de forme | EBX |
|---|---|
| Chipset Ethernet | RealTek RTL8139 |
| Système Chipset | VIA PC-133 |
| Puce vidéo | VIA VT8606 |
| Audio | Realtek ALC202 AC’97 codec, AC’97 2.0 compliant, Mic-in, Line-in, CD Audio-in, Line-out, Speaker-out |
| Battery | Lithium 3 V/196 mAH |
| BIOS | AWARD® 256 kbit Flash BIOS |
| Cache Memory | 256 KB/512 KB on ULV Celeron/LV Pentium III processor |
| Jeu de puces | VIA® Twister chip with Integrated S3 Savage4 2D/3D/Video Accelerator VT8606, VT82C686B, 133 MHz FSB |
| Contrôleur | RealTek® RTL8139DL |
| UNITÉ CENTRALE | Embedded Ultra Low Voltage Intel Celeron or Low Voltage Pentium III Processor, on-die 32 KB L1 cache memory ULV Celeron-400 (PCM-9579F-J0A1E), ULV Celeron-650 (PCM-9579F-M0A1E), LV Pentium III-933 (PCM-9579F-R0A1E) |
| Dimensions | 203 x 146 mm (8″ x 5.75″) 0.85 kg (weight of total package) |
| Interface d'expansion | PC/104-Plus (ISA & PCI) and PCI slot |
| I/O Chipset | 2 x EIDE (Ultra DMA 100), 1 x FDD, 1 x K/B, 1 x Mouse, 1 x RS-232/422/485, 3 x RS-232, 1 x LPT |
| Entrée | RJ45 by cable |
| IR Interface | 115 kbps, IrDA 1.1 compliant |
| LCD Controller | 2-Channel (2 x 18-bit) LVDS interface |
| LCD Interface | 4X AGP VGA/LCD interface, Support for 18, 24, 36-bit TFT and 16 or 24-bit DSTN panels up to SXGA resolution |
| Mémoire | 8/16/32 MB frame buffer using system memory |
| Humidité de fonctionnement | 0% ~ 90% relative humidity, non-condensing |
| Température de fonctionnement | 0 ~ 60° C (32 ~ 140° F) |
| Consommation électrique | Max.: 4.5 A @ +5 V (with 256 MB, ULV Celeron-650) Typical: 2.99 A @ +5 V (with 256 MB DRAM, ULV Celeron-400 CPU) 3.29 A @ +5 V (with 256 MB DRAM, ULV Celeron-650 CPU) |
| Power Management | APM 1.1, ACPI Support |
| Alimentation électrique | +5 V ±5% |
| Processeur | -20 ~ 70° C (accessories Storage temperature: -20 ~ 60° C) Intel LV Celeron |
| Programming | 95% @ 60° C |
| Resolutions | CRT Mode: 1280 x 1024 @ 16 bpp (60 Hz), 1024 x 768 @ 16 bpp (85 Hz), LCD/Simultaneous Mode: 1280 x 1024 @ 16 bpp (60 Hz), 1024 x 768 @ 16 bpp (60 Hz) |
| Speed | 10/100 Mbps |
| SSD | CompactFlash® card Type I/II and DiskOnChip® |
| Mémoire du système | SDRAM 168-pin PC/100 or 1 x 133 DIMM, Max: 512 MB |
| System Monitor | IEEE 802.3u 100BASE-T Fast Ethernet compatible Built-in boot ROM in Flash BIOS |
| TV-out | Supports both NTSC/PAL, S-video and Composite Video |
| USB | 4 x USB ports, USB 1.1 compliant |
| Minuterie chien de garde | 1 – 62 sec, 62 level interval timer, system reset or IRQ11 |
