Caractéristiques
| Facteur de forme | PCI |
|---|---|
| Chipset Ethernet | Intel 82551 |
| Système Chipset | VIA Mark |
| Battery | Lithium 3 V/210 mAH |
| BIOS | AWARD 256 KB Flash BIOS |
| Jeu de puces | VIA Mark CoreFusion processor VIA VT82C686B |
| Contrôleur | Intel 82551ER |
| UNITÉ CENTRALE | Embedded low power onboard VIA Mark 533 MHz processor |
| Dimensions | 96 x 90 mm (3.8″ x 3.5″) |
| I/O Chipset | 1 x EIDE, 1 x FDD, 1 x K/B, 1 x mouse, 2 x RS232, 1 x LPT |
| IR Interface | 1 x 115 kbps SIR, IrDA 1.0 compliant |
| LCD Controller | Supports 2 channel (2 x 18-bit) LVDS interface |
| LCD Interface | Supports 1 channel 24-bit LVDS LCD Panel (TTL signal) |
| Mémoire | 8/16/32 MB frame buffer shares the system memory |
| Humidité de fonctionnement | 0% ~ 90% relative humidity, non-condensing |
| Température de fonctionnement | 0 ~ 60° C (32 ~ 104° F), operation |
| Consommation électrique | Max: +5 V @ 1.94 A, Typical: +5 V @ 2.06 A |
| Power Management | APM 1.2 |
| Alimentation électrique | AT, +5 V ±5%, +12V ±5% (5V only, 12V optional for PC104 add on card and LCD inverter) |
| Processeur | VIA Mark |
| Resolutions | CRT display mode pixel resolution up to 1600 x1200 x 16 bpp LVDS display Mode up to SXGA (1400 x 1050) panel resolution |
| Speed | IEEE 802.3 10 Base-T, IEEE 802.3u 100 Base-TX Fast Ethernet Compatible |
| Température de stockage | 64 KB |
| Mémoire du système | 1 x 144-Pin SODIMM 8/16/32/64/128/256/512 MB SDRAM |
| USB | 2 x USB 1.1, Open HCI compliant |
| Minuterie chien de garde | 62 lever timer (Optional flexible interval available) |
| Poids | 0.097 kg (0.214 lb) |
