| Facteur de forme | ATX |
|---|---|
| Chipset Ethernet | Intel 82540EM |
| Système Chipset | Intel ICH4 Intel 855GME + ICH4 |
| Puce vidéo | Intel 855GME |
| 2nd Cache Memory | 1 or 2 MB on Pentium M processor, 512 KB/1 MB on Celeron M |
| Audio | Support AC97 Audio with optional PCM-231A-00A1 |
| Battery | Lithium 3 V/196 mAH |
| BIOS | AWARD 4 Mbit Flash BIOS |
| Built-in Boot ROM | 82540EM and 82551QM (optional) |
| Jeu de puces | Intel 82540EM (Gigabit), Intel 82551ER/82551QM (optional) Intel 855GME chip integrated. (Extreme Graphics 2) |
| UNITÉ CENTRALE | Embedded Intel Pentium M (Banias/Dothan)/Celeron M Processor supported, Celeron M 600 MHz (512 KB): PCI-6881F-M0A1, Pentium M 1.1 GHz: PCI-6881F-S0A1 uFCPGA2(478pin): PCI 6881F-00A1/PCI-6881FG-00A1 |
| Dual Independent Display | CRT + LVDS |
| Interface d'expansion | 32-bit PCI slot |
| GPIO | 8-bit general purpose input/output |
| I/O Expansion | PCI |
| Interface E/S | 2 x EIDE (1 x Ultra DMA100,1 x Ultra DMA33), 1 x FDD, 1 x K/B, 1x Mouse, 1 x RS-232/422/485, 3 x RS-232, 1 x LPT |
| Interface | RJ-45 |
| IrDA | N/A |
| LCD Interface | 2 Channel LVDS (48-bit) |
| LVDS Interface | Hirose connector support dual channel LVDS panel |
| Taille de la mémoire | Optimized Shared Memory Architecture, supports up to 64 MB frame buffer using system memory |
| Power Management | APM 1.2, ACPI supported |
| Processeur | Intel Pentium M |
| Résolution | CRT Mode: up to 2048 x 1536 @ 75 Hz, LVDS Mode: up to 1280 x 1024 @ 48 bpp up to UXGA panel resolution with frequency range from 25 MHz to 112 MHz |
| Speed | 10/100Base-T, 10/100/1000Base-T |
| SSD | Support CompactFlash® Card Type I/II |
| Standard | IEEE 802.3 z/ab (1000Base-T) or IEEE 802.3u (100 Base-T) protocol compatible |
| Mémoire du système | 200 pin SODIMM x 2, support ECC DDR up to 2 GB |
| TV-out | N/A |
| USB | 4 USB ports, USB 2.0 compliant |
| Watch Dog Timer | 0-255 sec, System reset or IRQ11 |
