Innolux P070ACG-AZ1 LCD

Specification

Model P/N:P070ACG-AZ1
Brand:Innolux
Diagonal Size:7.0"
Resolution:600(RGB)×1024, WSVGA 170PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 50% NTSC
Backlight:WLED , 15K hours , No Driver
Signal Type:MIPI (4 data lanes) , 40 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:89.28(W)×152.37(H) mm
Bezel Opening:-
Treatment:Hard coating
Luminance:350 cd/m² (Typ.)
Outline(mm):95 × 163.3 × 4.5 (H×V×D)
Response:10/15 (Typ.)(Tr/Td) ms
Good View at:Symmetry
Work Mode:IPS, Normally Black, Transmissive
Mass:TBD
Used for:Pad & Tablet
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3/10.0/21.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: -10 ~ 50 °C
