Chimei Innolux M280DGJ-Q02 LCD

Specification

Model P/N:M280DGJ-Q02
Brand:Chimei Innolux
Diagonal Size:28.0"
Resolution:3840(RGB)×2160, UHD 157PPI
Brightness:0 cd/m²
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:85/85/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOB
Pixel Format:RGB Vertical Stripe
Active Area:620.928(W)×341.28(H) mm
Bezel Opening:-
Response Time:1.5/3.5 (Typ.)(Tr/Td)
Outline Size:635.028(W)×355.33(H) ×1.43(D) mm
Surface:Antiglare (Haze 25%), Hard coating (3H)
Best View on:6 o'clock
Display Colors:1.07B 70% NTSC
Lamp Type:No B/L
Frequency:60Hz
Touch Screen:Without
Panel Weight:2.91/3.06Kgs (Typ./Max.)
Application:Desktop Monitor
Signal Interface:V-by-One 8 lane , 51 pins Connector
Input Voltage:12.0V (Typ.)
Driver IC:COFBuilt-in 12 source + 4 gate chips
Glass Depth:0.50+0.50 mm
Transmissivity:4.06% (Typ.)(with Polarizer)
