AT070TN92 V.X Century LCD panel replacement

Brand：CTC–
Model：AT070TN92 V.X
Diagonal Size：7.0 inch
Type：a-Si TFT-LCD, CELL
Pixel Format：800(RGB)×480[WVGA]
Configuration： RGB Vertical Stripe
Active Area：154.08(H)×85.92(V) mm
Outline Dim.：162.5(H)×96.62(V)×1.43(D) mm
Bezel Area：-
Treatment：Antiglare
Luminance：0 cd/m2
Contrast Ratio： 500:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：10/15 (Typ.)(Tr/Td)
Viewing Angle：70/70/50/70 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Plate Thickness：0.50+0.50 mm
Transmittance：5.11% (Typ.)(with Polarizer)
Support Color：16.7M 50%(CIE1931)
Light Source：No B/L, W/O Driver
Weight： 45.0g (Typ.)
Designed For： MP4 PMP, Digital Photo Frame, Portable DVD Player,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 50 pinsParallel RGB (1 ch, 8-bit), FPC
Power Supply：3.3/10.4/16.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL)
Environment： Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
