QD15XL06 Rev.01 QDI LCD panel replacement for Laptop

Panel Brand：QDI
Panel Model：QD15XL06 Rev.01
Panel Size：15.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1024(RGB)×768 , XGA
Pixel Format：RGB Vertical Stripe
Display Area：304.128(W)×228.096(H) mm
Bezel Opening：307.53(W)×231.5(H) mm
Outline Size：317.3(W)×242(H)×5.9(D) mm
Surface：Antiglare, Hard coating (3H), Reflection 5.0% (Max.)
Brightness：160 cd/m2 (Typ.)
Contrast Ratio：300:1 (Typ.) (TM)
Viewing Angle：45/45/15/35 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：8/17 (Typ.)(Tr/Td)
Display Colors：262K
Lamp Type：1 pcsCCFL, 10K hours, Without Driver
Frequency：60Hz
Touch Screen：Without
Shape Style： Wedge (PCBA Bent, Depth ≥5.2mm)
Application： Laptop,
Signal Interface： LVDS (1 ch, 6-bit), 30 pins, Connector
Input Voltage：3.3V (Typ.)
Environment：Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
