Manufacturer：IVO
Model Name：M101NWWB R3
Screen Size：10.1 inch
Screen Type：LCM ,a-Si TFT-LCD
Pixel Number：1280(RGB)×800 (WXGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)： 216.96 × 135.6 (H×V)
Outline(mm)：229.46 × 149.1× 4.56 (H×V×D)
Bezel Area(mm)： –
Treatment： Glare (Haze 0%), Hard coating (3H)
Luminance：350 cd/m2 (Typ.)
Contrast Ratio：800 : 1 (Typ.) (TM)
Viewing Angle： 85/85/85/85 (Typ.)(CR≥10)
Response： 25 (Typ.)(Tr+Td) ms
Good View at： Symmetry
Work Mode： IPS, Normally Black, Transmissive
Color Depth：16.7M 45%(CIE1931)
Backlight：WLED, 15K hours, With LED Driver
Mass： 160g (Max.)
Used for： Industrial Application, Pad & Tablet,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type：LVDS (1 ch, 8-bit), Connector, 40 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings：Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
