T-55335D150J-FW-A-AAN Kyocera LCD panel replacement

Manufacturer：OPTREX
Screen Size： 15.0 inch
Pixel Number： 1024(RGB)×768(XGA)
Active Area(mm)：304.128 × 228.096 (H×V)
Bezel Area(mm)：308.1 × 232.1 (H×V)
Luminance：1500 (Typ.)(cd/m2)
Viewing Angle：70/70/50/60 (Typ.)(CR≥10)
Good View at：6 o’clock
Color Depth：262K/16.7M 50% (CIE1931)
Mass： 1.90Kgs (Typ.)
Refresh Rate：60Hz
Model Name：T-55335D150J-FW-A-AAN1 Compatible
Screen Type：LCM ,a-Si TFT-LCD
Arrangement：RGB Vertical Stripe
Outline(mm)： 326 × 267(H×V×D)
Treatment：Antiglare, Hard coating (3H)
Contrast Ratio： 650 : 1 (Typ.) (TM)
Work Mode： TN, Normally White, Transmissive
Response：6/19 (Typ.)(Tr/Td) ms
Backlight：6 pcs CCFL , 50K hours , No Driver
Used for： Industrial Application, Outdoor High Brightness,
Touchscreen：Without
Signal Type：LVDS (1 ch, 6/8-bit), Connector, 20 pins
Voltage Supply： 3.3V (Typ.)
Max. Ratings： Storage Temp.: -20 ~ 80 °C Operating Temp.: -20 ~ 70 °C
