BOE HM236WU1-110 LCD

Specification

Model P/N:HM236WU1-110
Brand:BOE
Diagonal Size:23.6"
Resolution:1920(RGB)×1080, FHD 93PPI
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:85/85/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:521.28(W)×293.22(H) mm
Bezel Opening:525.22(W)×297.22(H) mm
Outline Dim:544.8(H)×320.5(V) ×9.6(D) mm
Treatment:Antiglare (Haze 25%), Hard coating (3H)
Luminance:250 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:1.5/3.5 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:16.7M 72% NTSC
Light Source:WLED [4 strings] , 30K hours , W/O Driver
Weight:2.20Kgs (Typ.)
Designed For:Desktop Monitor
Frame Rate:75Hz
Touch Panel:Without
Interface Type:LVDS (2 ch, 8-bit) , 30 pins Connector
Power Supply:5.0V (Typ.)
