CPT CLAD015GB01 AX LCD

Specification

Model P/N:CLAD015GB01 AX
Brand:CPT
Diagonal Size:1.54"
Resolution:240(RGB)×240 219PPI
Contrast Ratio:500 : 1 (Typ.) (TM)
Viewing Angle:45/45/45/25 (Typ.)(CR≥10)
Color Depth:262K 60% NTSC
Backlight:No B/L
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Empty Cell)
Pixel Format:RGB Vertical Stripe
Active Area:27.72(W)×27.72(H) mm
Bezel Opening:-
Treatment:Without Polarizer
Luminance:0 cd/m²
Response:15/15 (Typ.)(Tr/Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Wearable ，Square Display
Refresh Rate:-
Touchscreen:Without
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):30.32×32.72×1 (H×V×D)
Driver IC list:Suggest COG ST7789HS, ST7789V
Transmissivity:10% (Typ.)(without Polarizer)
Glass Thickness:0.50+0.50 mm
