IVO C045SWY1-B LCD

Specification

Model P/N:C045SWY1-B 5
Brand:IVO
Diagonal Size:4.5"
Resolution:480(RGB)×854, FWVGA 219PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:70/70/70/60 (Typ.)(CR≥10)
Color Depth:16.7M 60% NTSC
Backlight:No B/L
Panel Type:a-Si TFT-LCD, CELL , Full Cell, Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:55.44(W)×98.637(H) mm
Bezel Opening:-
Treatment:Without Polarizer
Luminance:0 cd/m²
Response:20 (Typ.)(Tr+Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:12.3g
Used for:Mobile Phone
Refresh Rate:60Hz
Touchscreen:Without
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):58.44×106.337×0.8 (H×V×D)
Driver IC list:Suggest COG ILI9806C-1
Transmissivity:4.5% (Typ.)(with Polarizer)
Glass Thickness:0.40+0.40 mm
