BOE HM150X01-N02 LCD

Specification

Model P/N:HM150X01-N02
Brand:BOE
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Contrast Ratio:700 : 1 (Typ.) (TM)
Viewing Angle:40/40/22/45 (Typ.)(CR≥10)
Color Depth:262K/16.2M 60% NTSC
Backlight:9S3P WLED , 50K hours , With LED Driver
Signal Type:LVDS (1 ch, 6/8-bit) , 20 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:307.3(W)×231.3(H) mm
Treatment:Antiglare (Haze 25%), Hard coating (3H)
Luminance:350 cd/m² (Typ.)
Outline(mm):326.5 × 253.5 × 10 (H×V×D)
Response:8 (Typ.)(Tr+Td) ms
Good View at:-
Work Mode:TN, Normally White, Transmissive
Mass:TBD
Used for:Industrial
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
